Glass combination pH electrode for testing general purpose liquids.

About P11 Rod Glass Combination pH Electrode BNC.

• This pH electrode is combination type (has built in reference) and is supplied with 1 metre of cable and a BNC plug as standard.
• If an additional cable length or alternative plug is required, please specify when ordering.

Applications:

• Liquids general purpose with toughened membrane.

Specifications

• Shelf Life: 12 months
• Body Type: Glass
• Cable Length: 1 Metre
• Connector: BNC (others available upon request)
• pH Range: 0-14
• E O Point: -25mV to +25mV
• Temperature Range oC: 0-80
• Response Time: & 30 secs 95% FSD
• Ref. Type: AgCl, Liquid filled, Single Junction
• Junction Type: Annular Ceramic
• Shaft Length: 120mm 2mm
• Shaft Dia. mm: 11.8-12.2mm
