About P18 Spear Electrode Combination pH Electrode BNC.

• This pH electrode is combination type (has built in reference) and is supplied with 1 metre of cable and a BNC plug as standard.

Applications

• Slurries, Soil Measurement

Specifications

• Shelf Life: 12 months
• Body Type: Glass
• Cable Length: 1 Metre
• Connector: BNC (others available upon request)
• pH Range: 0-14
• E O Point: -25mV to +25mV
• Temperature Range oC: 0-80
• Ref. Type: AgCl, Liquid Filled Single Junction
• Junction Type: Annular Ceramic
• Shaft Length: 120mm mm
• Stem Dia. mm: 11.8 - 12.2mm
